Fortinet FortiGate FG-601E

Name: Fortinet FortiGate FG-601E
Brand: Movantech Systems Pvt Ltd
Price: 1039797.0 INR
Availability: InStock

Price 1039797.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Fortinet FortiGate FG-601E Specification

Usage
Network Security

Part
Hardware Appliance

Technique
ASIC-accelerated hardware

Design
High-density front I/O panel

Thickness
Standard 1U form

Humidity
20% to 90% non-condensing

Temperature
Operating: 0C to 40C

Mounting Type
Rackmount

Processing
High Performance Threat Protection

Supply Voltage
100-240V AC, 50-60 Hz

Surface Treatment
Powder Coated

Finish
Matte/Texture

Output Voltage
12V internal DC

Installation Guideline
Rackmount installation, follow vendor instructions

Dimension (L*W*H)
432 x 370 x 44 mm

Service Period
As per subscription/service contract

RAM
8 GB DDR4

Product Type
Next-Generation Firewall (NGFW)

Brand Name
Fortinet

Equipment Type
Network Security Appliance

Standard
Complies with FCC/CE/VCCI standards

Application
Enterprise & Data Center protection

Input Voltage
100-240V AC

CPU Support
Multi-core processor

Material
Metal and Electronic Components

Process
Inline Network Inspection

Color
Black/Silver

Frequency
50/60 Hz

Size
1U Rackmount

Weight
Approx. 8 kg

Model No
FG-601E

Compliance
Common Criteria, FIPS 140-2

New Sessions/Second
150,000

Storage
128 GB SSD (onboard)

VPN Throughput
14 Gbps

Management Ports
2x GE RJ45 MGMT

SSL Inspection Performance
1.8 Gbps

Interfaces
12x GE RJ45, 4x GE SFP, 2x 10GE SFP+

Power Supply
Dual Redundant, Hot-swappable

Concurrent Sessions
3 Million

Firewall Throughput
Up to 20 Gbps

High Availability
Supported (Active/Passive, Active/Active)

Threat Protection Throughput
Up to 2.5 Gbps

Maximum Number of Policies
10,000

Fortinet FortiGate FG-601E About

Fortinet FortiGate FG-601E

The Fortinet FortiGate FG-601E is an enterprise-grade Next-Generation Firewall (NGFW) designed for large enterprises, data centers, and service providers requiring advanced security with integrated onboard storage for enhanced logging and analytics. Powered by Fortinets NP6 and CP9 Security Processing Units (SPUs), it delivers high-performance threat protection, intrusion prevention (IPS), application control, web filtering, SSL inspection, secure IPsec and SSL VPN connectivity, integrated SD-WAN, and Zero Trust Network Access (ZTNA). Equipped with an internal SSD for local logging, reporting, and forensic analysis, the FG-601E provides high-speed 10 Gigabit connectivity, hardware-accelerated security processing, and centralized management through FortiOS and the Fortinet Security Fabric for mission-critical enterprise and hybrid cloud environments.

Applications: Large Enterprises, Data Centers, Service Providers, Campus Core Networks, Secure SD-WAN Deployments, Internet Edge Security, Zero Trust Network Access (ZTNA), Local Log Storage and Analytics, Hybrid Cloud Connectivity, High-Speed Network Segmentation, Remote Access VPN, and Advanced Threat Protection.

Enterprise-Grade Performance

The FG-601E is designed for organizations requiring high throughput and advanced protection. Its ASIC-accelerated architecture provides efficient threat mitigation without compromising on speed, making it ideal for enterprise and data centers.

Resilient and Scalable Design

Boasting hot-swappable dual redundant power supplies, the appliance ensures continuous operation during maintenance or unexpected power events. Its rackmount, 1U form and flexible interface options support seamless scaling as your network grows.

Comprehensive Threat Protection

With up to 2.5 Gbps threat protection throughput and robust SSL inspection capabilities, the FG-601E addresses modern security needs, defending against sophisticated threats in real-time while maintaining network performance.

FAQ's of FG- 601E:

Q: How is the FG-601E typically installed in an enterprise environment?

A: The FG-601E is designed for 1U rackmount installation, making it easy to integrate into standard data center racks. Fortinet recommends following their detailed installation guidelines to ensure secure and optimal setup.

Q: What are the main benefits of using the FG-601E for network security?

A: The main benefits include high firewall throughput (up to 20 Gbps), advanced threat protection (up to 2.5 Gbps), and extensive interface options for connectivity. Its resilient design with hot-swappable redundant power supplies ensures maximum uptime and business continuity.

Q: When should I consider deploying the FG-601E in my organization?

A: The FG-601E is best suited for businesses or data centers that require scalable, high-throughput security appliances capable of managing millions of concurrent sessions and demanding real-time inspection needs.

Q: Where can the FG-601E operate effectively in terms of environmental conditions?

A: The appliance operates reliably in temperatures from 0C to 40C and humidity between 20% to 90% (non-condensing), making it suitable for most controlled data center or server room environments.

Q: What process does the FG-601E use to inspect and mitigate network threats?

A: The FG-601E leverages inline network inspection aided by hardware acceleration (using ASICs and a multi-core processor) to rapidly analyze traffic, enforce security policies, and provide real-time threat mitigation without bottlenecks.

Q: How does the high availability feature benefit my network?

A: High availability (active/passive and active/active) ensures that your network remains protected, even during appliance failures or maintenance. This minimizes downtime and safeguards business operations round the clock.
